Policy based routing MICRO-HOWTO
Horacio J. Peña, horape@compendium.com.ar
v0.03 05/Apr/2000

1. Preface, disclaimer and help request.

This is my attempt to recopilate some info on how to use the advanced
routing capabilities of the 2.1.x Linux kernels. As each time i've
asked for help in linux-(kernel|net|router|es) instead of getting answers
i received lots of mail saying "You seem to know how to use iproute,
could you explain me it?" i'm writing that so i can send them an URL :-)

I DON'T KNOW NOTHING OF POLICY ROUTING FOR SURE. All of these notes
are based on my guesses about how that works. I HAVEN'T READ THE
CODE (i tried, but i got lost very quickly, i promise retry when
i wake up) ALL OF WHAT YOU DO BASED ON THIS DOCUMENT IS YOUR AND
ONLY YOUR RESPONSABILITY. I wasn't. You haven't seen me. You
cannot prove it. And i apologize for my english, i'm hard enough
to understand writing in Spanish (too confuse), so i imagine it
will be real hard reading me in English.

I'm not maintaining actively this document (i'm updating it now, in Apr/2000,
and last mod was from Nov/1998)

This micro HOWTO will probably vanish with somebody that knows
really about this issue writing the corresponding section of
the NET-3 (NET-4?) HOWTO.

I'll assume you know enough of tcp/ip and the standard routing
principles. If you don't please read before the NET-3 HOWTO and
the NAG.

1.1. History.

v0.1 and v0.2. Original and grammatical corrections. (End of 1998)

v0.3 added "Routing

2. Required software.

You'll need a recent 2.1.x kernel (i've a pair of production machines
running 2.1.119 from some weeks ago and my work devel machine runs
2.1.129) compiled with policy routing. (depends on Networking Options/
IP: advanced router)

You will need too the iproute2 package. You can get it from
ftp.inr.ac.ru:/ip-routing (there are lots of interesting things
there), but it can be hairy to compile, so if your distro has
it as package use it. (i know for sure that Debian has it)

You probably will want to use ipchains. And read its wonderful
HOWTO (at least for the ASCII art ;). You can find ipchains in
http://www.adelaide.net.au/~rustcorp/.

3. Basics.

In the traditional (2.0) routing you had a routing table. Now you
have a rules table that point to multiple routing tables. The rules
let you select the routes based not only on the destination address,
but in the source address, TOS, and incoming device.

Added to that, you can use the very expressive ipchains rules to
route using more details (transport protocol headers)

4. Rules.

Rules are defined by the "ip rule" command. Let's see its syntax:

Usage: ip rule [ list | add | del ] SELECTOR ACTION
SELECTOR := [ from PREFIX ] [ to PREFIX ] [ tos TOS ]
[ dev STRING ] [ pref NUMBER ]
ACTION := [ table TABLE_ID ] [ nat ADDRESS ]
[ prohibit | reject | unreachable ]
TABLE_ID := [ local | main | default | NUMBER ]

(I haven't played yet with NAT, and don't understand what
"[ prohibit | reject | unreachable ]" does here (isn't it an
ipchains work?), so, by now, the only ACTION we'll be using is
table.)

4.1. Listing rules.

The command to list the rules table is "ip rule list", more often
abbreviate as "ip ru ls".

Look at its output:

0: from all lookup local
32766: from all lookup main
32767: from all lookup default

(default output)

0: from all lookup local
2000: from all lookup 2
3000: from all lookup 3
3500: from all tos 04 lookup 32
4000: from 192.168.0.14 lookup 4
4000: from 192.168.0.3 lookup 4
4000: from 192.168.0.121 lookup 4
4000: from 192.168.0.30 lookup 4
32000: from all lookup 32
32766: from all lookup main
32767: from all lookup default

(output in my main router)

The number at the left of the colon is the preference. When a packet
arrives to the system it gets compared with the SELECTOR of each rule
in preference order, (don't know what happens with equal preference
rules), if it matches then the ACTION is done.

4.2. Adding a rule.

The command to add a rule is "ip ru add SELECTOR ACTION". Some examples:

4.2.1. Routing by TOS.

ip ru add tos 4 pref 3500 table 32

generates the rule

3500: from all tos 04 lookup 32

That means: For all packets with the IP header TOS field == 4
use the routing table 32.

4.2.2. Routing by source

This is probably the most used feature of policy routing.

ip ru add from 10.20.30.40 table 5

generates the rule

1: from 10.20.30.40 lookup 5

(preference can differ, it assigns the first unused one)

That means: for all packets originated from the IP 10.20.30.40
use routing table 5.

4.3. Deleting a rule.

Same syntax than for add but using "ip ru del"

5. Routing tables.

These are handled by "ip route" ("ip ro" for the friends)

The syntax is very similar to the good old route's one:

Usage: ip route list SELECTOR
ip route { change | del | add | append | replace | monitor } ROUTE
SELECTOR := [ root PREFIX ] [ match PREFIX ] [ exact PREFIX ]
[ table TABLE_ID ] [ proto RTPROTO ]
[ type TYPE ] [ scope SCOPE ]
ROUTE := NODE_SPEC [ INFO_SPEC ]
NODE_SPEC := [ TYPE ] PREFIX [ tos TOS ]
[ table TABLE_ID ] [ proto RTPROTO ]
[ type TYPE ] [ scope SCOPE ]
INFO_SPEC := NH OPTIONS FLAGS [ nexthop NH ]...
NH := [ via ADDRESS ] [ dev STRING ] [ weight NUMBER ] NHFLAGS
OPTIONS := FLAGS [ mtu NUMBER ] [ rtt NUMBER ] [ window NUMBER ]
TYPE := [ unicast | local | broadcast | multicast | throw |
unreachable | prohibit | blackhole | nat ]
TABLE_ID := [ local | main | default | all | NUMBER ]
SCOPE := [ host | link | global | NUMBER ]
NHFLAGS := [ onlink | pervasive ]
RTPROTO := [ kernel | boot | static | NUMBER ]

Oops, it seems a bit more complex than route's one... :-)

But, for now, just use it as route.

5.1 Listing routing tables.

ip ro ls [table N]

The output will be similar to:

192.168.0.0/24 dev eth1 scope link
10.10.0.0./16 via 192.168.0.5 dev eth1
default via 192.168.0.15 dev eth1

5.2. Adding routes.

ip ro add destination/dstmsk [dev DEV] [via GATEWAY] [table TABLE]

Examples:

ip ro add 192.168.0.0/24 dev eth1 table 3
ip ro add 0.0.0.0/0 via 200.16.189.211 table 32

5.3. Deleting routes.

ip ro del destination/dstmsk [dev DEV] [via GATEWAY] [table TABLE]

ip ro del 192.168.0.0/24 dev eth1 table 3
ip ro del 0.0.0.0/0 table 32

6. Routing by firewall mark.

The most common scenary i receive questions about is a router with
two connections to the internet. The good and expensive and the cheap
and bad... So we would like to send the priority traffic for the good
one, and the standard routing system doesn't give us enough flexibility.

Here comes ipchains to the rescue! It provides us the added flexibility
and let us to route based in transport protocol headers.

The way to do it is by adding a firewall rule to the input chain, that
marks the packet and adding a routing rule to process it.

Remember to compile your kernel with CONFIG_IP_ROUTE_FWMARK.

6.1. Marking packets.

The marking of packets must be done in the input chain (or on a chain
called from the input one) to be useful. That's because the routing
decissions are taken before the packet hits the forward rule (that's
a assumption, i haven't read the code yet O:-) and of course before
the output chain...

An interesting note about this is that you can only route with this
added flexibility packets generated non locally. It would be interesting
to add a "local" chain...

To mark a packet add a rule like that: (check the ipchains HOWTO for the
syntax)

ipchains -A input -p tcp -s 192.168.0.0/24 -d 0/0 22 -m 2

(This means, mark all the ssh -tcp port 22- traffic with 2 as mark value)

6.2. Using the mark.

Use fwmark in the routing rule definition.

ip ru add fwmark 2 table 4 pref 2500
ip ro add 0/0 dev ppp0 table 4

6.3. Masquerading.

With this, you can determine what connection will be used for sending out
the packets, but if you want to decide where will the answer come by, you'll
need to do masquerading...

ipchains -A forward -p tcp -s 192.168.0.0/24 -d 0/0 22 -j MASQ

(in this example, you'd need to do masquerade the same, because we're using
private IPs)

7. More info.

There is now documentation for iproute2! Look for ip-cref in the
iproute files.

8. Credits and legalities.

8.1. Thanks.

To Linus, _Anarchy_, Alexey, Paul, David, etc. for his great
work on my preferred TCP/IP stack. :-)

To Arne Kuhlmann, JOshua, Enrique I.R. and Lindsay Allen, that
have convinced me to write that.

To the UniNet crowd, MJ, Mapi, pukka, pask, ciberio, etc. for their
patience.

To the PuntoAr people that let me work on thinks i enjoy, without
bothering with stupid burocratic things.

8.2 Legalities.

This document is free software; you can redistribute it and/or modify
it under the terms of the GNU General Public License as published by
the Free Software Foundation; either version 2 of the License, or (at
your option) any later version.

This document is distributed in the hope that it will be useful, but
WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU
General Public License for more details.

You should have received a copy of the GNU General Public License
along with this program; if not, write to the:

Free Software Foundation, Inc., 675 Mass Ave, Cambridge, MA 02139,
USA.
